Shopfront SF100

CAD Downloads

Shopfront SF100 Downloads

Utilizing a 100mm Mullion

SF100 System - Single Glazed Seismic

Download files.

SF100 Double Door - Flush Single Glazed

Download files

SF100 Double Door - Flush Double Glazed

Download files

SF100 Slider - Double Glazed Single Track Double Door

Download Files

SF100 Slider - Double Glazed Double Track Triple Door

Download Files

Specification

Aluminium shopfronts are produced in 6060 T5 Alloy. T4 alloy may be used if shopfront sections are required to be curved or rounded.

We recommend using Masterspec 4251TS Commercial Windows when specifying this suite.

Finishes

Shopfronts can be supplied in 20 or 25 micron anodic films for external use and 12 or 20 micron finish for internal use. Clear, light bronze, mid bronze, dark bronze and black anodised finished can be supplied and specials on request. Electrostatic polyester powdercoating finishes can be supplied in a number of colours and architectural grades.

Polyester powder coat - both standard and special colours available.
Anodised - all anodised colours available - commercial grade 20 micron finish recommended.
PVF2 Fluorocarbon finishes - Available on request.

Colour brochures from paint companies can be provided on request.
