Sheet Metal Cladding Systems

Sheet metal offers architects tremendous design flexibility with a vast array of materials and different finishes to select from, and the versatility to be folded into 3D shapes, curved, laser cut and perforated or expanded into mesh.

ENCLAD™ is Thermosash’s proprietary range of bracket profiles engineered specifically to support rainscreen cladding.

ENCLAD™ Rainscreen Support Systems are adjustable to accommodate cavity depth requirements, insulation and firestops and take up building construction tolerances.

Sheet Metal Cladding Support - EN01

ENCLAD™ EN01 - Visible Fixed: suitable for thin smooth cladding.

Download PDF showing window, door and wall abutment plan views, sections and details.

Sheet Metal Cladding Support - EN04

ENCLAD™ EN04 - Hook On Secret Fixed: suitable for large size or heavy weight cladding.

Download PDF for window, door and wall abutment plan views, sections and details.

Sheet Metal Cladding Support - EN05-FF

ENCLAD™ EN05-FF - Hook On Secret Fixed: for cladding where floor to floor spans are required (i.e. non-load bearing walls).

Download PDF for window, door and wall abutment plan views, sections and details.

Specification

We recommend using Masterspec 4216IR RAINSCREEN CLADDING SUPPORT SYSTEM when specifying this system type.

Finishes

ENCLAD™ SYSTEMS

Polyester powdercoat - both standard and special colours available. (Polyester powder organic coating in accordance with WGANZ PQAS and AS 3715, and AAMA 2604).
