NZI Centre

Project Overview

NZI Centre, 1 Fanshawe Street, Auckland was completed in 2010. The NZGBC 5.5 Star Green Star Rating for Office Design was awarded to the NZI Centre in 2015.

2010 Awards:

  • Property Council NZ Award - Interior - Supreme Winner
  • NZIA New Zealand Architecture Award - Commercial Architecture
  • NZIA New Zealand Architecture Award – Sustainability
  • NZIA New Zealand Architecture Award - Interior Architecture

The high-performance facade is double glazed on the southern and eastern sides of the building. The northern facade is twin-skin tripple glazed. The western facade is protected by solar shading. Facing east is a 21m high internal atrium, which is overlooked by all office floors.

Thermosash facade solution delivered;

  • PW1000 Unitised curtainwall with feature beads to the outer skin
  • Integrated maintenace walkways with the twin skin facade
  • Itesticial mechanised blinds linked to the BMS
  • CW600 total vision inner system with vertical butt glazed glass fins with high performance IGUs
  • Ventilated facade soffit/parapet closures
  • PW600 Unitised system to the ground floor
  • Delta Seismic Commercial Windows to the West elevation
  • Atrium IGU Thermosash Alpha skylights
  • Auto doors



Scarbro Construction
