Mechanical Air Louvre 156mm Triple Bank

CAD Downloads


The Thermosash high performance triple bank mechanical air louvre systems integrate into the Thermosash range of curtainwall and commercial window systems for façade integrated mechanical air inlet and extract requirements. These louvres are commonly specified as fresh air inlets for mechanical plant and mechanical plant screening.

Product: MAL-156T  |  [Type 4]

Triple Bank Louvres

Download files

PW1000 with Triple Bank Louvre

Download files


Thermosash Mechanical Air Louvres - Brochure

November 2023


Due to the potential unique and high performance design requirements, a bespoke specification will be created by a mechanical or facade engineer consultant.

When integrated with Thermosash suites and referencing the inclusion we recommend using Masterpec 4211TS Curtainwalls and 4251TS Commercial Windows.

Please contact us to discuss your project early in conceptual development.

  • Specify double or triple bank - when a greater degree of weather proofing is required


  • Extrusions are high performance polyester powdercoated or anodised, prior to manufacturing.
  • Polyester powder organic coating in accordance with WGANZ PQAS and AS 3715, and AAMA 2604.
